I use [projen](https://github.com/projen/projen) for almost all of my projects because it allows me to not worry about all of the very necessary but tedious parts of a project - `.gitignore`, `.eslintrc.json`, GitHub Actions workflows, etc. However, I often find myself having both a front end and back end in the same repository. While projen and [GitHub Actions](https://github.com/features/actions) will automatically take care of upgrading dependencies in my main folder, I also want it to take care of dependencies in other parts of my project.

## Schedule

For the main folder dependencies, once a day upgrades is very aggressive. We can adjust that in our `.projenrc.js` file to weekly:

```javascript
const { UpgradeDependenciesSchedule } = require('projen/lib/javascript');

const project = new awscdk.AwsCdkTypeScriptApp({
  ...projectConfig,
  depsUpgradeOptions: {
    ignoreProjen: false,
    workflowOptions: {
      labels: ['auto-approve', 'auto-merge'],
      schedule: UpgradeDependenciesSchedule.WEEKLY,
    },
  },
});
```

This pushes our `upgrade` workflow out to [once a week](https://crontab.guru/#0_0_*_*_1):

```yaml
name: upgrade
on:
  workflow_dispatch: {}
  schedule:
    - cron: 0 0 * * 1
```

## Additional Actions

To add an action, we will once again edit our `.projenrc.js` file. This time we will add a workflow.

```javascript
const { JobPermission } = require('projen/lib/github/workflows-model');

const upgradeSite = project.github.addWorkflow('upgrade-site');
upgradeSite.on({ schedule: [{ cron: '0 0 * * 1' }], workflowDispatch: {} });
```

This will create a new workflow on the same schedule as the existing `upgrade` workflow.

Next, we will add a job that will:

- Install dependencies via `yarn`
- Upgrade dependencies
- Create a Pull Request

```javascript
upgradeSite.addJobs({
  upgradeSite: {
    runsOn: ['ubuntu-latest'],
    name: 'upgrade-site',
    permissions: {
      actions: JobPermission.WRITE,
      contents: JobPermission.READ,
      idToken: JobPermission.WRITE,
    },
    steps: [
      { uses: 'actions/checkout@v3' },
      {
        name: 'Setup Node.js',
        uses: 'actions/setup-node@v3',
        with: {
          'node-version': '16',
        },
      },
      {
        run: 'yarn install --check-files --frozen-lockfile',
        workingDirectory: 'site',
      },
      { run: 'yarn upgrade', workingDirectory: 'site' },
      {
        name: 'Create Pull Request',
        uses: 'peter-evans/create-pull-request@v4',
        with: {
          'token': '${{ secrets.' + AUTOMATION_TOKEN + ' }}',
          'commit-message': 'chore: upgrade site',
          'branch': 'auto/projen-upgrade',
          'title': 'chore: upgrade site',
          'body': 'This PR upgrades site',
          'labels': 'auto-merge, auto-approve',
          'author': 'github-actions <github-actions@github.com>',
          'committer': 'github-actions <github-actions@github.com>',
          'signoff': true,
        },
      },
    ],
  },
});
```

Adjust the `workingDirectory` as needed for any directory that has dependencies that can be upgraded.

## Result

Now, we will have a weekly GitHub Actions workflow that will upgrade dependencies for both our main folder, as well as a subfolder of our choosing. This can be used to help keep [Dependabot](https://github.com/dependabot/dependabot-core) alerts to a minimum by keeping up with security updates.

```yaml
name: upgrade-site
on:
  schedule:
    - cron: 0 5 * * 1
  workflow_dispatch: {}
jobs:
  upgradeSite:
    name: upgrade-site
    runs-on: ubuntu-latest
    permissions:
      actions: write
      contents: read
      id-token: write
    steps:
      - uses: actions/checkout@v3
      - name: Setup Node.js
        uses: actions/setup-node@v3
        with:
          node-version: '16'
      - run: yarn install --check-files --frozen-lockfile
        working-directory: site
      - run: yarn upgrade
        working-directory: site
      - name: Create Pull Request
        uses: peter-evans/create-pull-request@v4
        with:
          token: ${{ secrets.PROJEN_GITHUB_TOKEN }}
          commit-message: 'chore: upgrade site'
          branch: auto/projen-upgrade
          title: 'chore: upgrade site'
          body: This PR upgrades site
          labels: auto-merge, auto-approve
          author: github-actions <github-actions@github.com>
          committer: github-actions <github-actions@github.com>
          signoff: true
```


This article will show you how to add custom GitHub Actions workflows with Projen

Custom GitHub Action workflows with projen


# CDK Websocket Server

In this demo, we see how to build a simple WebSocket server using Amazon Elastic Container Service with Fargate. This demo also includes an [Amazon CloudFront Distribution](https://docs.aws.amazon.com/AmazonCloudFront/latest/DeveloperGuide/distribution-working-with.html), [Application Load Balancer](https://aws.amazon.com/elasticloadbalancing/application-load-balancer/), and [Auto Scaling group](https://docs.aws.amazon.com/autoscaling/ec2/userguide/auto-scaling-groups.html). This will allow the server to scale up as needed while using TLS to secure the communication.

![Overview](/images/blog/WebSocketOverview.png)

## ECS Fargate

## Docker Build

```Dockerfile
FROM --platform=linux/arm64 node:20
WORKDIR /usr/src/app
COPY . .
RUN yarn && yarn build
EXPOSE 8080
CMD [ "node", "dist/server.js" ]
```

The Docker build is a simple Typescript based server that runs on NodeJS. This Dockerfile will copy the contents of the source directory and use `tsc` to transpile the Typescript file into Javascript before running.

### Cluster and Auto Scaling Group

First we will create the cluster that our container will run in.

```typescript
this.cluster = new Cluster(this, 'Cluster', {
  vpc: props.vpc,
  clusterName: 'websocket-service',
});

const autoScalingGroup = new AutoScalingGroup(this, 'AutoScalingGroup', {
  vpc: props.vpc,
  instanceType: new InstanceType('m6i.large'),
  machineImage: EcsOptimizedImage.amazonLinux2(),
  desiredCapacity: 1,
});

autoScalingGroup.role.addManagedPolicy(
  ManagedPolicy.fromAwsManagedPolicyName('AmazonSSMManagedInstanceCore'),
);

const capacityProvider = new AsgCapacityProvider(this, 'capacityProvider', {
  autoScalingGroup: autoScalingGroup,
});

this.cluster.addAsgCapacityProvider(capacityProvider);
```

This cluster is running in a newly created VPC and includes an Auto Scaling Group.

### Fargate Task Definition

Next, we will create a Fargate container that will run our WebSocket Server. This will consist of several configurations that need to work together.

```typescript
const webSocketTask = new FargateTaskDefinition(
  this,
  'WebSocketTaskDefinition',
  {
    memoryLimitMiB: 2048,
    cpu: 1024,
    runtimePlatform: {
      operatingSystemFamily: OperatingSystemFamily.LINUX,
      cpuArchitecture: CpuArchitecture.ARM64,
    },
    taskRole: websocketServiceRole,
  },
);
```

Here we are setting up the basics of our compute. This Task will use `ARM64` compute. All components must be configured to use the same type of compute.

### Fargate Container

Next we will set up our container.

```typescript
webSocketTask.addContainer('WebSocketContainer', {
  image: ContainerImage.fromAsset('src/resources/containerImage'),
  containerName: 'websocket-service',
  portMappings: [{ containerPort: 8080, hostPort: 8080 }],
  logging: LogDrivers.awsLogs({
    streamPrefix: 'websocket-service',
  }),
  healthCheck: {
    command: ['CMD-SHELL', 'curl -f http://localhost:8080/health'],
    interval: Duration.seconds(30),
    timeout: Duration.seconds(30),
  },
  environment: {},
});
```

There are several key components here.

#### Port Mappings

In this example, we are using port `8080` on the container and host. Later we will see how to map the public facing port to this port.

#### Health Check

This container is also configured to perform periodic health checks to verify the container is running correctly. In this example, we are running a `curl` on the server.

### Fargate Service

Finally, we will create the Service using the previously created Task.

```typescript
const websocketService = new FargateService(this, 'WebSocketService', {
  cluster: this.cluster,
  taskDefinition: webSocketTask,
  assignPublicIp: true,
  desiredCount: 1,
  vpcSubnets: { subnetType: SubnetType.PUBLIC },
  securityGroups: [webSocketServiceSecurityGroup],
  enableExecuteCommand: true,
});
```

With the Fargate created, we can tie this to an Application Load Balancer.

#### Security Group

To ensure that only the Application Load Balancer can make requests to the Fargate container, we will attach a Security Group to the Fargate Service and allow the Application Load Balancer Security Group access to it.

```typescript
const albSecurityGroup = new SecurityGroup(this, 'ALBSecurityGroup', {
  vpc: props.vpc,
  description: 'Security Group for ALB',
  allowAllOutbound: true,
});

webSocketServiceSecurityGroup.connections.allowFrom(
  new Connections({
    securityGroups: [albSecurityGroup],
  }),
  Port.tcp(8080),
  'allow traffic on port 8080 from the ALB security group',
);
```

## Application Load Balancer

```typescript
this.applicationLoadBalancer = new ApplicationLoadBalancer(
  this,
  'ApplicationLoadBalancer',
  {
    vpc: this.vpc,
    internetFacing: true,
  },
);
```

The Application Load Balancer is created and associated with the VPC.

### Target Group

```typescript
const webSocketTargetGroup = new ApplicationTargetGroup(
  this,
  'webSocketTargetGroup',
  {
    vpc: props.vpc,
    port: 8080,
    protocol: ApplicationProtocol.HTTP,
    targets: [websocketService],
    healthCheck: {
      path: '/',
      protocol: Protocol.HTTP,
      port: '8080',
    },
  },
);
```

First, we will create a Target Group. This is where traffic will be sent. Here we can see port `8080` as the port to send traffic to on the container. This corresponds to the port exposed on the Fargate container. This Target Group will forward requests to the Fargate Service. This Application Load Balancer also includes a health check. This health check is different from the previously created health check as the Application Load Balancer is initiating this check rather than the container itself.

### Listener

```typescript
const webSocketListener = props.applicationLoadBalancer.addListener(
  'webSocketListener',
  {
    port: 80,
    protocol: ApplicationProtocol.HTTP,
    open: true,
    defaultAction: ListenerAction.fixedResponse(403),
  },
);

webSocketListener.addAction('ForwardFromCloudFront', {
  conditions: [
    ListenerCondition.httpHeader(props.customHeader, [props.randomString]),
  ],
  action: ListenerAction.forward([webSocketTargetGroup]),
  priority: 1,
});
```

Next we will create a Listener. Here we can see the listener is listening on port `80`. This is where we made the conversion from port `80` to port `8080`. We are using Protocol `HTTP`. The server will upgrade this HTTP request to WebSocket when it is received.

### Actions

To [restrict access to the Application Load Balancer](https://docs.aws.amazon.com/AmazonCloudFront/latest/DeveloperGuide/restrict-access-to-load-balancer.html) we will be adding a unique header to the CloudFront Distribution and a corresponding condition on the Application Load Balancer.

We do that here by creating a default action that responds with a `403`. This means that the Application Load Balancer will reject any request unless it includes a specific Header and Value. In this case, the Application Load Balancer will forward the request to the `webSocketTargetGroup`. We will be adding this Header and Value on the Origin of the CloudFront Distribution in the next step.

Note that the Application Load Balancer is using `HTTP` and not `HTTPS`. We will be enforcing `HTTPS` at the Cloudfront Distribution layer. Be only allowing traffic to our Application Load Balancer from our CloudFront Distribution, we can enforce `HTTPS` be used from the Client. This allows us to create a secure connection without a owning a domain that can be used to generate the certificate.

## Cloudfront Distribution

Finally, we will create our CloudFront Distribution. This will be used to provide TLS to our Application Load Balancer.

```typescript
const defaultOrigin = new LoadBalancerV2Origin(props.applicationLoadBalancer, {
  httpPort: 80,
  protocolPolicy: OriginProtocolPolicy.HTTP_ONLY,
  originId: 'defaultOrigin',
});

this.distribution = new Distribution(this, 'Distribution', {
  defaultBehavior: {
    origin: defaultOrigin,
    viewerProtocolPolicy: ViewerProtocolPolicy.HTTPS_ONLY,
    cachePolicy: CachePolicy.CACHING_DISABLED,
    allowedMethods: AllowedMethods.ALLOW_ALL,
    originRequestPolicy: OriginRequestPolicy.ALL_VIEWER,
  },
  defaultRootObject: 'index.html',
  priceClass: PriceClass.PRICE_CLASS_100,
  logBucket: distributionLoggingBucket,
  enableLogging: true,
});
```

Here we are creating a CloudFront Distribution that only accepts HTTPS. This will create a certificate that is used by the Distribution. This Distribution will send that traffic to our Application Load Balancer on port `80`.

### Custom Header

In order to provide the security outlined above using Custom Headers and Values, we must add those Headers and Values to the Origination. Unfortunately, that feature does not existing natively in CDK. Therefore, we will use a Custom Resource to add the Headers and Values.

```typescript
new CustomResource(this, 'customHeaderCustomResource', {
  serviceToken: customHeaderCustomResourceProvider.serviceToken,
  properties: {
    DistributionId: this.distribution.distributionId,
    Origins: [
      {
        OriginId: 'defaultOrigin',
        CustomHeaders: [
          {
            HeaderName: props.customHeader,
            HeaderValue: props.randomString,
          },
        ],
      },
    ],
  },
});
```

Using the previously created Distribution, we will pass the information to our Custom Resource that will be added to the Distribution.

### Custom Resource

```typescript
const updatedOrigins = Distribution.DistributionConfig!.Origins!.Items!.map(
  (origin: any) => {
    const matchedOrigin = Origins.find((o: any) => o.OriginId === origin.Id);
    if (matchedOrigin) {
      return {
        ...origin,
        CustomHeaders: {
          Quantity: matchedOrigin.CustomHeaders.length,
          Items: matchedOrigin.CustomHeaders.map((header: any) => ({
            HeaderName: header.HeaderName,
            HeaderValue: header.HeaderValue,
          })),
        },
      };
    }
    return origin;
  },
);
```

Within the Custom Resource, we will `GetDistributionConfiguration` and match up the origin with the desired Header and Value. Using this updated configuration, we will `UpdateDistributionConfiguration`. Now, when a request is made to our CloudFront Distribution, it will add this Header and Value to the request to the Application Load Balancer. This, in turn, will forward the request to our Fargate Service.

## Results

We have now created an auto-scaling, load-balanced application that is secured with `HTTPS` using a CloudFront Distribution. This will allow you to build a secure WebSocket server that will automatically adapt to your traffic needs.

## Deployment

To deploy this demo, simply run:

```bash
yarn launch
```

## Removal

This demo does include services that can accumulate costs, so be sure to remove when not needed. To delete:

```
yarn cdk destroy
```

You may have to manually delete the Auto Scaling Group if it is not able to automatically delete.

## Repo

https://github.com/schuettc/cdk-websocket-server


This demo will show how to build and deploy a Fargate WebSocket server.  This application will automatically scale and use TLS to secure the connection.

Building and Deploying a WebSocket server with Fargate and CDK


![Overview](/images/blog/KDSReader.png)

In this demo, we see how to build a React based Websocket reader to get information from a Kinesis Data Stream to a client in real-time. This can be useful for viewing the contents of a Kinesis Data Stream.

## Components

### Websocket API

This demo uses an [Amazon API Gateway using WebSockets](https://docs.aws.amazon.com/apigateway/latest/developerguide/apigateway-websocket-api.html). Three routes are configured in this API Gateway: $connect, $disconnect, and $default. Connect and Disconnect are used to control connections to the API Gateway. These requests are passed to the Lambda function and stored in the DynamoDB.

```typescript
this.webSocketApi = new WebSocketApi(this, 'webSocketApi', {});

this.webSocketApi.addRoute('$connect', {
  integration: new WebSocketLambdaIntegration(
    'ConnectIntegration',
    this.lambdaHandler,
  ),
});
this.webSocketApi.addRoute('$disconnect', {
  integration: new WebSocketLambdaIntegration(
    'DisconnectIntegration',
    this.lambdaHandler,
  ),
});
this.webSocketApi.addRoute('$default', {
  integration: new WebSocketLambdaIntegration(
    'DefaultIntegration',
    this.lambdaHandler,
  ),
});
```

### Lambda Handler

When the request is made to the Lambda function, the request is processed and information about the connection stored in the DynamoDB.

```typescript
export const handler: Handler = async (event) => {
  if (isAPIGatewayProxyEvent(event)) {
    // WebSocket connection and disconnection handling
    const connectionId = event.requestContext.connectionId;
    console.log('endpoint:  ' + process.env.API_GATEWAY_ENDPOINT);

    if (event.requestContext.eventType === 'CONNECT') {
      await ddbDocClient.send(
        new PutCommand({
          TableName: process.env.CONNECTION_TABLE,
          Item: { connectionId },
        }),
      );
      return { statusCode: 200 };
    } else if (event.requestContext.eventType === 'DISCONNECT') {
      await ddbDocClient.send(
        new DeleteCommand({
          TableName: process.env.CONNECTION_TABLE,
          Key: { connectionId },
        }),
      );
      return { statusCode: 200 };
    }
```

This information will be used when a Kinesis Data Stream record is used to [invoke the Lambda function](https://docs.aws.amazon.com/lambda/latest/dg/with-kinesis.html).

```typescript
this.lambdaHandler = new NodejsFunction(this, 'lambdaHandler', {
  entry: 'src/resources/handler/index.ts',
  runtime: Runtime.NODEJS_18_X,
  architecture: Architecture.ARM_64,
  timeout: Duration.seconds(60),
  role: lambdaHandlerRole,
  environment: {
    STREAM_NAME: props.kinesisDataStream.streamName,
    CONNECTION_TABLE: props.connectionTable.tableName,
    API_GATEWAY_ENDPOINT: `https://${this.webSocketApi.apiId}.execute-api.${this.webSocketApi.stack.region}.amazonaws.com/${this.webSocketStage.stageName}`,
  },
});

new EventSourceMapping(this, 'eventSourceMapping', {
  target: this.lambdaHandler,
  eventSourceArn: props.kinesisDataStream.streamArn,
  startingPosition: StartingPosition.LATEST,
});
```

Here we see the Lambda function being created and `EventSourceMapping` used to trigger the Lambda when a record is added to the Kinesis Data Stream.

```typescript
  } else if (isKinesisStreamEvent(event)) {
    // Kinesis Data Stream processing
    for (const record of event.Records) {
      const kinesisData = Buffer.from(record.kinesis.data, 'base64').toString(
        'utf8',
      );
      console.log('Kinesis Record:', kinesisData);

      const connections = await ddbDocClient.send(
        new ScanCommand({ TableName: process.env.CONNECTION_TABLE }),
      );
      const postData = JSON.parse(kinesisData);

      if (connections.Items) {
        console.log('Connections: ' + JSON.stringify(connections.Items));
        for (const connection of connections.Items) {
          try {
            await apiGatewayManagementApi.send(
              new PostToConnectionCommand({
                ConnectionId: connection.connectionId,
                Data: new TextEncoder().encode(JSON.stringify(postData)),
              }),
            );
          } catch (error) {
            if (
              error instanceof Error &&
              'statusCode' in error &&
              error.statusCode === 410
            ) {
              // Remove stale connections
              await ddbDocClient.send(
                new DeleteCommand({
                  TableName: process.env.CONNECTION_TABLE,
                  Key: { connectionId: connection.connectionId },
                }),
              );
            }
          }
        }
      }
    }
  }
```

Now, when the Lambda is triggered by a KDS event, the Lambda will check if there are any active connections in the DynamoDB. If there are, the record will be written to the API Gateway.

### Client

In the client we will create a connection to the API Gateway so we can receive messages as they arrive.

```typescript
useEffect(() => {
  const ws = new WebSocket(WEB_SOCKET_URL + '/' + WEB_SOCKET_STAGE);

  ws.onopen = () => {
    console.log('Connected to WebSocket');
    setSocket(ws);
    setConnected(true);
  };

  ws.onmessage = (event) => {
    console.log('Received message:', event.data);
    const data: Message = JSON.parse(event.data);
    setMessages((prevMessages) => [...prevMessages, data]);
  };

  ws.onerror = (error: Event) => {
    console.error('WebSocket error:', error);
  };

  ws.onclose = () => {
    console.log('WebSocket connection closed');
    setSocket(null);
    setConnected(false);
  };

  return () => {
    if (ws) {
      ws.close();
    }
  };
}, []);
```

Once the client establishes a connection to the API Gateway, when a message is received, the data will be saved to State and displayed.

```typescript
return (
  <div className='header'>
    {connected ? (
      <div style={{ color: 'green' }}>WebSocket connected</div>
    ) : (
      <div style={{ color: 'red' }}>WebSocket disconnected</div>
    )}
    <button onClick={clearMessages}>Clear</button>
    <div className='messages'>
      <h2>Messages</h2>
      <ul className='message-list'>
        {messages.map((message, index) => (
          <li key={index} className='message'>
            <MessageItem message={message} />
          </li>
        ))}
      </ul>
      <AlwaysScrollToBottom />
    </div>
  </div>
);
```

## GitHub

This demo can be found here: https://github.com/schuettc/react-websocket-reader-for-kds

## Deploy

To deploy this demo:

```
yarn launch
```

## Cleanup

To destroy these components:

```
yarn cdk destroy
```


In this demo, we will be building a React based WebSocket reader that uses Amazon API Gateway to read data from a Kinesis Data Stream

Creating a React based WebSocket reader for KDS


# Multiple CPU Architecture CDK Deployment of an Asterisk to ECS Fargate

This demo contains a CDK deployment of an Asterisk server to Amazon ECS using Fargate. This will allow us to deploy an Asterisk server to a Docker container.

[https://github.com/schuettc/cdk-fargate-asterisk](https://github.com/schuettc/cdk-fargate-asterisk)

## Docker Image

For this demo, we will be using the [andrius/asterisk](https://github.com/andrius/asterisk) Docker image.

## Asterisk Configuration

To allow for customized configuration, we will copy files from the local directory to the Asterisk server in the `Dockerfile`.

```docker
COPY config/* /etc/asterisk
COPY docker-entrypoint.sh /
RUN chmod +x /docker-entrypoint.sh
```

In this example, we are copying in several files for our configuration including a `pjsip.conf` and `extensions.conf` files.

```asterisk
[udp]
type=transport
protocol=udp
bind=0.0.0.0
external_media_address=PUBLIC_IP
external_signaling_address=PUBLIC_IP
allow_reload=yes
```

In the [`pjsip.conf`](https://github.com/schuettc/cdk-fargate-asterisk/blob/main/src/resources/asterisk/config/pjsip.conf) file, we are simply loading a basic `udp` transport. We will configure this during deployment later.

## Multiple Build Platforms

In order to accommodate deployments from multiple platforms, we will ensure that the deployed version matches the built version.

In the [`Dockerfile`](https://github.com/schuettc/cdk-fargate-asterisk/blob/main/src/resources/asterisk/Dockerfile) we will use `${BUILDPLATFORM}` to make sure we're building using the local architecture. We need to do this because we are copying files to the image and then building it before deploying it.

```docker
FROM --platform=${BUILDPLATFORM} andrius/asterisk
```

In the [`ecs.ts`](https://github.com/schuettc/cdk-fargate-asterisk/blob/main/src/ecs.ts) file, we will determine the local architecture and use that.

```typescript
let deployArch: CpuArchitecture;
const cpuArch = os.arch();
if (cpuArch === 'arm64') {
  deployArch = CpuArchitecture.ARM64;
} else {
  deployArch = CpuArchitecture.X86_64;
}
```

Then, when we create the Task, we will use that `deployArch` as part of the build for the `cpuArchitecture`.

```typescript
this.task = new FargateTaskDefinition(this, 'TaskDefinition', {
  memoryLimitMiB: 2048,
  cpu: 1024,
  runtimePlatform: {
    operatingSystemFamily: OperatingSystemFamily.LINUX,
    cpuArchitecture: deployArch,
  },
  taskRole: asteriskTaskRole,
  volumes: [
    {
      name: 'asteriskLogs',
      efsVolumeConfiguration: {
        fileSystemId: fileSystem.fileSystemId,
        transitEncryption: 'ENABLED',
        authorizationConfig: {
          accessPointId: asteriskAccessPoint.accessPointId,
          iam: 'ENABLED',
        },
      },
    },
  ],
});
```

Now the deployed version will match the locally built version.

For example, when the Docker image is built on an M1 Mac, the Architecture type will be `ARM64`.

![ARM64](/images/blog/ARM64.png)

However, if the Docker image is built on an X86 based CPU, the Architecture type will be `X86_64`.

![X86_64](/images/blog/X86_64.png)

## Access the Asterisk Server

Once deployed, the Asterisk server can be accessed using [`ecs-execute`](https://docs.aws.amazon.com/AmazonECS/latest/developerguide/ecs-exec.html)

Included in the output of the CDK will be several commands that can be copied to the terminal for ssh access.

To access the running Asterisk:

- Copy/paste the `CLUSTER=` command
- Copy/paste the `TASK=` command
- Copy/paste either `aws ecs execute-command` command

## Asterisk Configuration

During deployment of the Fargate container, the Dockerfile will use [`docker-entrypoint.sh`](https://github.com/schuettc/cdk-fargate-asterisk/blob/main/src/resources/asterisk/docker-entrypoint.sh) as it's `ENTRYPOINT`. Everything in that file will be executed. We can use this to configure the Asterisk during deployment.

```bash
echo "METADATA: " ${ECS_CONTAINER_METADATA_URI_V4}
curl -o metadata.json ${ECS_CONTAINER_METADATA_URI_V4}/task
cat metadata.json
TASK_ARN=$( curl ${ECS_CONTAINER_METADATA_URI_V4}/task | jq -r '.TaskARN' )
echo "TASK_ARN: " $TASK_ARN
CLUSTER=$( curl ${ECS_CONTAINER_METADATA_URI_V4}/task | jq -r '.Cluster' )
echo "CLUSTER: " $CLUSTER
ENI=$(aws ecs describe-tasks --tasks $TASK_ARN --cluster $CLUSTER | jq -r '.tasks[0].attachments[0].details[1].value' )
echo "ENI: " $ENI
PUBLIC_IP=$( aws ec2 describe-network-interfaces --network-interface-ids $ENI | jq -r '.NetworkInterfaces[0].Association.PublicIp' )
echo "PUBLIC_IP: ${PUBLIC_IP}"

sed -i "s/PUBLIC_IP/$PUBLIC_IP/g" /etc/asterisk/pjsip.conf
```

With this shell script, we will determine the `PUBLIC_IP` of the container that is running and use that to configure the `pjsip.conf` file. This can be expanded to configure other parts of the Asterisk server as needed.

## Deploy/Destroy

To deploy this demo:

```bash
yarn launch
```

To destroy this demo:

```bash
yarn cdk destroy
```


This CDK will deploy a an Asterisk server to AWS Fargate from multiple CPU architectures

Multiple CPU Architecture CDK Deployment of an Asterisk to ECS Fargate


# Deploying Cross-Region Certificates with AWS Cloudfront via CDK

[AWS Certificate Manager](https://aws.amazon.com/certificate-manager/) (ACM) can be used to deploy TLS certificates for use with things like [Amazon Cloudfront](https://docs.aws.amazon.com/AmazonCloudFront/latest/DeveloperGuide/Introduction.html). However, ACM certificates must be deployed in `us-east-1`. In order to deploy an ACM certificate and associate with a resource outside of `us-east-1`, a multiple stack deployment must be used. The repo here: [https://github.com/schuettc/cdk-cross-region-cloudfront](https://github.com/schuettc/cdk-cross-region-cloudfront) will show an example of this.

## Certificate Stack

The first stack to be deployed will be the `CertificateStack`. This stack will create a `Certificate` in the `us-east-1` region that can be used by a Cloudfront Distribution in another region.

```typescript
interface CertificateStackProps extends StackProps {
  siteSubdomain: string;
  domain: string;
  hostedZoneId: string;
}

export class CertificateStack extends Stack {
  siteCertificate: Certificate;
  constructor(scope: Construct, id: string, props: CertificateStackProps) {
    super(scope, id, props);

    const certificateResources = new CertificateResources(this, 'certificate', {
      siteSubdomain: props.siteSubdomain,
      domain: props.domain,
      hostedZoneId: props.hostedZoneId,
    });

    this.siteCertificate = certificateResources.siteCertificate;
  }
}

const app = new App();

const certEnv = {
  account: process.env.CDK_DEFAULT_ACCOUNT,
  region: 'us-east-1',
};

const certProps = {
  siteSubdomain: process.env.SITE_SUBDOMAIN || '',
  domain: process.env.DOMAIN || '',
  hostedZoneId: process.env.HOSTED_ZONE_ID || '',
};

const certStack = new CertificateStack(app, 'CertificateStack', {
  ...certProps,
  env: certEnv,
  crossRegionReferences: true,
});

app.synth();
```

Here we are explicitly declaring `us-east-1` as the region to deploy this `Stack` to because ACM certificates used with CloudFront _must_ use `us-east-1`. We are passing in to the `Stack` props from a `.env` file that will be used to create the `Certificate`. This `Certificate` will be used as input to the next `Stack`. Note that the `Stack` must take the input `crossRegionReferences: true` to let the next `Stack` use this `Certificate`.

## Site Stack

```typescript
interface SiteStackProps extends StackProps {
  siteCertificate: Certificate;
  siteSubdomain: string;
  domain: string;
  hostedZoneId: string;
}

export class SiteStack extends Stack {
  constructor(scope: Construct, id: string, props: SiteStackProps) {
    super(scope, id, props);

    const site = new SiteResources(this, 'site', {
      siteCertificate: props.siteCertificate,
      siteSubdomain: props.siteSubdomain,
      domain: props.domain,
      hostedZoneId: props.hostedZoneId,
    });

    new CfnOutput(this, 'distributionURL', {
      value: site.distribution.domainName,
    });

    new CfnOutput(this, 'siteUrl', {
      value: `https://${props.siteSubdomain}.${props.domain}`,
    });
  }
}

const app = new App();

const siteEnv = {
  account: process.env.CDK_DEFAULT_ACCOUNT,
  region: 'eu-central-1',
};

const siteProps = {
  siteCertificate: certStack.siteCertificate,
  siteSubdomain: process.env.SITE_SUBDOMAIN || '',
  domain: process.env.DOMAIN || '',
  hostedZoneId: process.env.HOSTED_ZONE_ID || '',
};

new SiteStack(app, 'SiteStack', {
  ...siteProps,
  env: siteEnv,
  crossRegionReferences: true,
});

app.synth();
```

Here we are creating a second `Stack` as part of this deployment. This `Stack` will deploy the actual website using the `Certificate` from the previous `Stack`. The props used for this `Stack` are the same as the previous `Stack` with the addition of the `Certificate` created in the first `Stack`. This `Stack` uses a typical Single-Page Application (SPA) deployment of S3 + CloudFront with a specific `Certificate` and `ARecord` assigned.

```typescript
this.siteBucket = new Bucket(this, 'websiteBucket', {
  publicReadAccess: false,
  removalPolicy: RemovalPolicy.DESTROY,
  autoDeleteObjects: true,
});

const hostedZone = HostedZone.fromHostedZoneAttributes(this, 'hostedZone', {
  zoneName: props.domain,
  hostedZoneId: props.hostedZoneId,
});

this.distribution = new Distribution(this, 'CloudfrontDistribution', {
  enableLogging: true,
  domainNames: [props.siteSubdomain + '.' + props.domain],
  certificate: props.siteCertificate,
  minimumProtocolVersion: SecurityPolicyProtocol.TLS_V1_2_2021,
  defaultBehavior: {
    origin: new S3Origin(this.siteBucket),
    viewerProtocolPolicy: ViewerProtocolPolicy.REDIRECT_TO_HTTPS,
    cachePolicy: CachePolicy.CACHING_DISABLED,
  },
  defaultRootObject: 'index.html',
});

new ARecord(this, 'clientSiteARecord', {
  zone: hostedZone,
  target: RecordTarget.fromAlias(new CloudFrontTarget(this.distribution)),
  recordName: props.siteSubdomain + '.' + props.domain,
});
```

The result will be an SPA deployed to S3 with a CloudFront Distribution that uses a specific URL from Route53 and a Certificate provided by ACM. This site can be deployed in any Region while the Certificate will be deployed in `us-east-1` as required by CloudFront.

![Distribution](/images/blog/Distribution.png)

## .env File

To deploy this demo, a `.env` file must be used. This `.env` file will contain the following:

```bash
SITE_SUBDOMAIN = 'cross-region-site'
DOMAIN = 'example.com'
HOSTED_ZONE_ID = 'Z00000000000000000000'
```

## Result

![Result](/images/blog/Cross-Region-Deploy-Result.png)

The result is an [SPA deployed](https://cross-region-site.subaud.io/) to a non `us-east-1` Region while still using an ACM Certificate used by CloudFront all deployed by CDK. Information on [cross-region certificates](https://docs.aws.amazon.com/cdk/api/v2/docs/aws-cdk-lib.aws_certificatemanager-readme.html#cross-region-certificates) is available on the AWS CDK Reference Documentation.

## Resources

- Github Repo: [https://github.com/schuettc/cdk-cross-region-cloudfront](https://github.com/schuettc/cdk-cross-region-cloudfront)


In order to deploy a Certificate with a CloudFront Distribution, a multi-stack CDK must be used to deploy the Certificate in us-east-1 and the SPA in a different Region.  This CDK deployment will show how to do that.

Deploy a Cross-Region SPA with Cloudfront using CDK


# Minecraft CDK Deployment using AWS Fargate

This [repo](https://github.com/schuettc/cdk-minecraft) will deploy an AWS Fargate based Minecraft server that uses Route 53 to update the service and activate the Minecraft server.

Much of the work here is based on the work by [doctorrat117](https://github.com/doctorray117) from [minecraft-ondemand](https://github.com/doctorray117/minecraft-ondemand).

## Overview

![Overview](/images/blog/Minecraft.png)

## .env File

The .env file used by this deployment includes several variables that will be referenced later. A sample .env file is included: [.env.sample](/.env.sample) and should be updated and renamed to `.env`.

```
MINECRAFT_EDITION = 'java'
SERVER_SUBDOMAIN = 'minecraft'
DOMAIN = 'example.com'
HOSTED_ZONE_ID = 'Z00000000000000000000'
MEMORY_SIZE = '8192'
CPU_SIZE = '4096'
SNS_EMAIL = 'admin@example.com'
STARTUP_MIN = '10'
SHUTDOWN_MIN = '20'
DEBUG = 'true'
```

A Route 53 domain and Hosted Zone ID is required for this deployment. These will be used to start the service.

### AWS Fargate Service

This deployment uses an AWS Fargate service to deploy two containers - the Minecraft server and a watchdog server. The Minecraft server is the reason for deploying this and will be used to play the game. The watchdog container is used to ensure that the Minecraft server is still being used.

#### Starting the Service

To start the service and allow someone to use the Minecraft server, a query to `SERVER_SUBDOMAIN`.`DOMAIN` will result in Route 53 updating Cloudwatch logs. This Cloudwatch log will trigger an AWS Lambda Function to set the `desired-count` of the Fargate service to 1.

```python
    if desired == 0:
        ecs.update_service(
            cluster=CLUSTER,
            service=SERVICE,
            desiredCount=1,
        )
        print("Updated desiredCount to 1")
    else:
        print("desiredCount already at 1")
```

By setting the `desired-count` to 1, the containers in the ECS service will be activated and available. The AWS ECS Service includes the Minecraft server container and a watchdog container. Both of these will be started when the `desired-count` is set to 1.

```typescript
this.service = new FargateService(this, 'FargateService', {
  serviceName: 'MineCraftService',
  cluster: this.cluster,
  capacityProviderStrategies: [
    {
      capacityProvider: 'FARGATE',
      weight: 1,
      base: 1,
    },
  ],
  taskDefinition: this.task,
  assignPublicIp: true,
  desiredCount: 0,
  vpcSubnets: { subnetType: SubnetType.PUBLIC },
  securityGroups: [props.securityGroup],
  enableExecuteCommand: true,
});

const minecraftServerContainer = this.task.addContainer(
  'MinecraftServerContainer',
  {
    image: ContainerImage.fromRegistry(props.serverConfig.image),
    environment: {
      EULA: 'TRUE',
      MEMORY: '8G',
    },
    portMappings: [
      {
        containerPort: props.serverConfig.port,
        hostPort: props.serverConfig.port,
        protocol: props.serverConfig.protocol,
      },
    ],
    essential: false,
    logging: props.serverConfig.debug
      ? new AwsLogDriver({
          logRetention: RetentionDays.THREE_DAYS,
          streamPrefix: 'minecraft',
        })
      : undefined,
  },
);

this.task.addContainer('WatchdogContainer', {
  image: ContainerImage.fromAsset(
    path.resolve(__dirname, './resources/watchdogContainer'),
  ),
  essential: true,
  environment: {
    CLUSTER: this.cluster.clusterName,
    SERVICE: 'MineCraftService',
    DNSZONE: props.subDomainHostedZoneId,
    SERVERNAME: `${props.serverSubDomain}.${props.domain}`,
    SNSTOPIC: props.snsTopic?.topicArn || '',
    STARTUPMIN: props.startupMin,
    SHUTDOWNMIN: props.shutdownMin,
  },
  logging: props.serverConfig.debug
    ? new AwsLogDriver({
        logRetention: RetentionDays.THREE_DAYS,
        streamPrefix: 'minecraft',
      })
    : undefined,
});
```

#### Stopping the Service

During normal operations, both the Minecraft container and Watchdog container will be active. The Minecraft server is used to play the game while the Watchdog server will monitor the activity of the Minecraft server. When the watchdog server determines that the Minecraft server has not been used for `SHUTDOWN_MIN`, the watchdog server will set the `desired-count` of the Fargate Service to 0. By setting the `desired-count` to 0, the containers will be stopped to reduce costs.

### Notification

When the AWS Fargate service starts or stops, a notification is sent to SNS.

```bash
function send_notification ()
{
  [ "$1" = "startup" ] && MESSAGETEXT="${SERVICE} is online at ${SERVERNAME}"
  [ "$1" = "shutdown" ] && MESSAGETEXT="Shutting down ${SERVICE} at ${SERVERNAME}"

  ## SNS Option
  [ -n "$SNSTOPIC" ] && \
  echo "SNS topic set, sending $1 message" && \
  aws sns publish --topic-arn "$SNSTOPIC" --message "$MESSAGETEXT"
}
```


This demo will use CDK to deploy a Minecraft server on AWS Fargate using Route 53 as the trigger
